FIRTREE PERIMETER & MEETING STILE SEAL

Stock Code:
KIIS0511-1000BLK-T6
$12.20
Description

Description

Incorporated into door assemblies for its medium temperature smoke and acoustic properties. Also used as a privacy seal on toilet cubicle doors.

This rigid PVC base seal has co-extruded flame retardant, twin flexible smoke and acoustic fins. It fits quickly and easily into a nominal 3mm (wide) by 5mm (deep) interference fit groove.

*This seal is available with either 4mm or 6mm fin height.

Gap Size
 6mm fin height > Min. 3mm / max. 5mm

Standard Lengths
 1000mm

Standard Colours
 Black
(white, grey & dark brown available to special order)

Approval
 Fire tested to AS1530 Part 4 in accordance with AS1905 Part 1
 Medium temperature smoke leakage approvals to AS1530 Part 7,
compliant with AS6905 on proprietary door assemblies
 Conforms with BCA Specification C3.4 smoke sealing requirements
 Acoustically tested in accordance with AS1191, IS0140.3
and ISO10140-2
 Durability tests demonstrating over 100,000 open
and close cycles
